Alarm System Improvement

On every production platform, plant, or facility, we want to avoid incidents, accidents, and interruptions. However, should anything occurs, we want the least amount of time to pass before we resume production.

Alarm System Improvement by Eldor_themepage

How to reach your goals for optimal production with alarm system improvement:

  1. What is an alarm system improvement project?
  2. Project cost
  3. How can you get started
Eldor has studied incidents and major accidents on offshore and onshore production facilities in great detail. We have a thorough understanding of the costs associated with poor alarm management, namely:
  • Major accidents and losses
  • Operator burnout
  • Loss of production, typically around 3-5%
In short: Alarm systems need to be specified and maintained in order to ensure safe operation.

What is an Alarm System Improvement project?

diamond_blue
diamond_black

What to look for

Alarm-Managment-Banner
Some common symptoms of an alarm system that needs to be improved are:
  • Minor process disturbances that produce a large amount of alarms
  • Routine operations that produce a large number of alarms with no action required
  • Alarm texts that are not understandable and offers little-to-no help
  • A large number of high priority alarms occur
  • Major process disturbances that produce alarm flooding



How do we approach the project?

Obviously, Alarm System Improvement projects can be time consuming and complicated, and require great attention to detail, while keeping up with the overall scope and progress of the project. Eldor has developed a documented practical alarm system improvement process, in order to keep track of everything for the project.
diamond_blue
diamond_black

1. Initial Alarm System Study

Alarm-Managment-Banner
  • Study and report of current alarm systems performance
  • Establish performance targets based on best practices
  • Establish philosophies and specifications

diamond_blue
diamond_black

2. Alarm System Improvement project

Alarm-Managment-Banner
  • Alarm cleaning (rationalisation) workshops with technicians and operators
  • Development of alarm response manual
  • Prepare job-packs for implementation into control and safety system
  • Implementation into control system
  • Training
  • Issue final report, documenting the resultant alarm system performance
diamond_blue
diamond_black

3. Alarm System Maintenance

Alarm-Managment-Banner
  • Regular alarm system health checks and KPI monitoring
  • Training of new personnel and new projects
  • Design review of major modification projects
  • Management of change (MoC) for alarm system

In addition, it is important to consider the need for management software.

diamond_blue
diamond_black

Applicable Standards & Software

Alarm-Managment-Banner
Eldor has been running alarm improvement projects for more than a decade, and have managed hundreds of workshops. We have experienced that good alarm management can be of vital importance in order to constantly improve alarm system performance. Our processes are in line with the most relevant standards such as EEMUA 191, ISA 18.2, IEC 62682 and YA711 .
Alarm-Managment-Banner
Some common symptoms of an alarm system that needs to be improved are:
  • Minor process disturbances that produce a large amount of alarms
  • Routine operations that produce a large number of alarms with no action required
  • Alarm texts that are not understandable and offers little-to-no help
  • A large number of high priority alarms occur
  • Major process disturbances that produce alarm flooding



How do we approach the project?

Obviously, Alarm System Improvement projects can be time consuming and complicated, and require great attention to detail, while keeping up with the overall scope and progress of the project. Eldor has developed a documented practical alarm system improvement process, in order to keep track of everything for the project.
Alarm-Managment-Banner
  • Study and report of current alarm systems performance
  • Establish performance targets based on best practices
  • Establish philosophies and specifications

Alarm-Managment-Banner
  • Alarm cleaning (rationalisation) workshops with technicians and operators
  • Development of alarm response manual
  • Prepare job-packs for implementation into control and safety system
  • Implementation into control system
  • Training
  • Issue final report, documenting the resultant alarm system performance
Alarm-Managment-Banner
  • Regular alarm system health checks and KPI monitoring
  • Training of new personnel and new projects
  • Design review of major modification projects
  • Management of change (MoC) for alarm system

In addition, it is important to consider the need for management software.

Alarm-Managment-Banner
Eldor has been running alarm improvement projects for more than a decade, and have managed hundreds of workshops. We have experienced that good alarm management can be of vital importance in order to constantly improve alarm system performance. Our processes are in line with the most relevant standards such as EEMUA 191, ISA 18.2, IEC 62682 and YA711 .

Project cost

The time-consumption for each configured alarm is in most cases between 10 to 15 minutes per alarm in a typical alarm system with 10.000 alarms. From this we can assume that if you have an alarm system with 10.000 alarms you will need to budget between 1.700 to 2.500 hours for the full Alarm rationalisation project.

Due to these projects highly customised nature, every project should be estimated on the basis of an initial study.
The most important cost variables for Alarm System Improvement projects are:
  • Client effort (vs. external resources)
  • Complexity/size of the plant
In general, an initial study will require a site visit with access to interviewing operators, in order to issue a study report. Indicative cost for an initial study may typically start from NOK 25.000.

How can you get started?

  • Step one is a system study, as the project scope and targets should be based on the initial condition
  • It is not feasible to run an Alarm System Improvement project without dedicated commitment from the plant or site operator
  • Additional involvement from client side is optional, based on availability of personnel and schedule


Unfortunately, some alarm improvement projects fail. In order to take part in our experience, we recommend to discuss the common pitfalls and success factors with us.



Contact us for more information.
